Functional features:

1, the rigid frame of the whole thick plate processing, each drum is independently configured with metal fiber infrared combustion system, saving energy and reducing costs.

2, the rigid frame of the whole thick plate processing, the flat and straight fine tube drawing roller, even if it is running at high speed, the linen and the conveyor belt will not run off;

3, the roller sprocket main drive and the pulley belt pair drive precision match, the speed is completely coordinated, improve the linen ironing degree;

4, conveyor belt and guide belt independent "self-tensioning" mechanism, so that the cloth pressure is more uniform, walking more smoothly;

5, the roller gradually differential speed design, effectively eliminate wrinkles: frequency conversion stepless speed regulation, smooth operation, and can intuitively display the working speed;

6, each drum is independently equipped with a set of metal fiber infrared combustion system, improve the reliability of the work and save energy consumption.
